Product codeARW 177268
1 078,72 EUR
1 046,81 EUR
/ pcs / incl. 23% VAT
Before we process the order with this product, the prepayment in the amount of 523,41 EUR may be required. Detailed information will be provided in the order summary, before its placement.
Easy return of products within 14days

For: universal

Borg Warner Airwerks turbochargers are designed for the competitive motorsports market as well as drivers retrofitting a naturally aspirated engine or looking for a little more performance from a factory turbocharged car.

Engineered specifically for drag racing, pulling and road racing, AirWerks turbochargers have earned a reputation as robust, brute-force induction systems. Looking for a no-frills replacement? Want to upgrade your turbocharger? Working with limited space? BorgWarner’s AirWerks turbochargers are the perfect go-to product for many applications.

With a twin hydrodynamic journal bearing design, AirWerks turbochargers feature an effective high-pressure ratio compressor stage, extended-tip technology and a high-efficiency turbine stage. The configuration provides ultra-fast response and more than 70 PSI of boost.

The Borg Warner AirWerks S200SX is available in few different configurations:

  • 0.83 A/R T4 Twin Scroll compressor wheel diameter 70/46 mm, compressor inlet 3" - P/N 177258
  • 1.09 A/R T4 Twin Scroll compressor wheel diameter 70/50 mm, compressor inlet 3" - P/N 177267
  • 0.83 A/R T4 Twin Scroll compressor wheel diameter 70/51 mm, compressor inlet 3" - P/N 177257
  • 1.22 A/R T4 Twin Scroll compressor wheel diameter 76/55.80 mm, compressor inlet 3" - P/N 177268
  • 1.22 A/R T4 Twin Scroll compressor wheel diameter 76/55.80 mm, compressor inlet 4" - P/N 178034
  • 1.27 A/R T4 Twin Scroll compressor wheel diameter 76/55.80 mm, compressor inlet 3" - P/N 178042

Features:

  • Twin hydrodynamic journal bearings
  • Extended tip technology compressor wheel
  • Twin scroll turbine housing
  • Adjustable compressor and turbine housing orientation
Product code
ARW 177268
General
Producer
Borg Warner
Series
Airwerks
Power range
220-580 KM
Engine capacity
2.5-5.0 l
Bearings
Twin hydrodynamic journal bearings
Warranty
12 months
Compressor side
Compressor wheel
Extended tip technology
Compressor inlet
76 mm (3")
Compressor wheel outer diameter
76 mm
Compressor wheel inducer diameter
55.80 mm
Compressor outlet
50.8 mm (2")
BOV
No
Turbine side
Turbine wheel
Inconel 713
Exhaust inlet
T4 Twin Scroll
A/R
1.22
Turbine wheel outer diameter
70 mm
Turbine outlet
V-band 4.21" (3/4 Marmon)
Wastegate
No
Boost control solenoid
No
12 months guarantee
12 months guarantee
